Home / All / Roof Structure System / 1111

1111

Categories	Roof Structure System
Trademark/Brand	PFM Architecture Service Provider
Model	ETFE
Type	Stadium Roofing Project
Structural System	Tensile Membrane Structure + Cable System
Roof Span	45 m
Roofing Materials	PTFE Membrane + High-Strength Steel Cables
Design Service Life	25–30 years (for membrane material)
Seismic Resistance	Designed for 8-degree rating
Construction Period	Approximately 8–10 months
Update Time	Oct 31,2025

Contact Now

Favorites

Detail Information

Quick Details

ETFE MEMBRANE ROOF SYSTEM

This project is part of the Guangzhou Macau Cooperation Zhuhai Hengqin Traditional Chinese Medicine Industrial Park project. The eaves of the membrane structure are 22 meters high, and the steel structure is made of elliptical customized steel pipes. The structure consists of six petals; The membrane material adopts German imported NOWOFOL frosted ETFE membrane material, with a simple structure and perfect shape, which is the finishing touch of the entire traditional Chinese medicine industry park.

-These project photos were provided by our partner TEXMOND.

Project Type	Membrane Roof Project
Structural System	ETFE Membrane Structure + Elliptical Steel Frame
Eaves Height	22 m
Roofing Materials	ETFE Membrane + Customized Elliptical Steel Pipes
Design Service Life	25–30 years (for membrane material)
Seismic Resistance	Designed for 8-degree rating
Structural Form	Six-petal Shaped Roof Structure
Construction Period	Approximately 8–10 months

Project Technical Solution

Structural System

The project adopts a hybrid structure combining ETFE membrane, cable, and customized elliptical steel frame. The six-petal design forms a lightweight, large-span roof, reducing structural weight and foundation loads while enhancing overall aesthetics.

Membrane (ETFE)

The roof uses ETFE membrane with high light transmission, UV resistance, and durability. Its frosted surface delivers soft, diffused daylight and excellent self-cleaning performance.

Cable System

The high-strength steel cable system works jointly with the ETFE membrane to ensure stable tension. This system offers excellent wind and seismic resistance, ensuring safety and durability under large-span configurations and diverse environmental conditions.

Project Highlights & Advantages

High-Performance ETFE

ETFE membrane delivers excellent light transmission, providing soft and natural indoor lighting. Its lightweight and flexible properties reduce structural load and maintenance costs, creating a comfortable and cost-efficient environment.

Long-Span & Structural Stability

Advanced structural design supports large-span ETFE membranes, ensuring superior safety and stability. The column-free interior provides flexible, open spaces suitable for a variety of uses.

Efficient Construction & BIM Management

Precise BIM-based planning and coordination streamline construction, minimize on-site errors, and accelerate project delivery, ensuring high-quality outcomes and predictable timelines.

Durability & Energy Efficiency

The ETFE membrane and supporting structure combination provides long-term durability and weather resistance. Its energy-efficient performance lowers operational costs while maintaining a sustainable and comfortable indoor environment.

Why Choose PFM

Specialized Solutions For Your Project

With rich international EPC experience, we offer PFM customized structural and roofing solutions tailored to each project's function, design, and architectural needs—ensuring efficient construction, unique appearance, and reliable performance.

A Variety of Combination Schemes
Combination Scheme		Structural Advantages	Functional Advantages	Typical Applications
Space Frame	Metal Roof	Long-span, lightweight, cost-effective	Simple modern appearance	Stadiums, exhibition halls, warehouses
	Glass Roof	High stiffness, stable structure	Excellent daylighting, transparency	Transport hubs, atriums, lobbies
Truss	Metal Roof	Flexible design, adaptable	Good daylighting	Museums, malls, greenhouses
	Glass Roof	High load capacity, durable	Transparent and open	Workshops, venues with hanging systems
Tensile Membrane	ETFE	Excellent durability, self-cleaning	Soft diffuse light	Stadium roofs, exhibition canopies
	PTFE	Ultra-lightweight, flexible, 90% transparency	Unique shapes, visually iconic	Stadium facades, atrium roofs, eco-greenhouses
steel structure	Metal Roof	Mature technology, reliable and strong	Industrial, modern appearance	Offices, factories, schools
Latticed Shell	Glass Skylight	High rigidity, large span	Abundant natural light, modern minimalist design	Commercial plazas, shopping centers
Other Customizable Parameters
Span Range	From 30 to 200 meters, tailored to specific project requirements.
Seismic Rating	Designed to meet seismic intensity levels from 6 to 9.
Material Options	Including Q235/Q355 structural steel, ETFE membrane, weathering steel, and more.
Sustainable Design	Compliant with green building standards, featuring energy-efficient roofing to reduce energy consumption.
Construction Method	Modular prefabrication to shorten construction time and reduce on-site risks.

Our Supply Capacity

Design Capability

A professional structural design team skilled in complex spatial modeling, structural analysis, and optimized design, ensuring the roofing system is safe, visually appealing, and cost-effective.

Procurement Capability

Long-term partnerships with top manufacturers of steel structures and roofing systems enable flexible material and system selection, guaranteeing both quality and delivery timelines.

Construction Capability

An experienced international engineering team specializes in large-span roof structures and systematic installation, ensuring high-standard, on-time project delivery.

Through an integrated Design–Procurement–Construction (DPC) supply model, PFM delivers stable and reliable turnkey roofing solutions—minimizing risk and reducing overall costs for clients.
